Q941F Q941Y Electric Ball Valve

[Product Description] Q941F and Q941Y PN16~PN63 electric ball valves: electric drive, flange connection, floating ball through type, valve seat sealing surface materials include fluoroplastic (Q941F) and hard alloy (Q941Y), nominal pressure PN16~PN63, nominal size DN15~DN300, suitable temperature -29~450 ℃, valve body materials include carbon steel, stainless steel, and alloy steel. Q941F and Q941Y PN16~PN63 electric ball valves are suitable for two position cut-off and adjustment situations. The connection between the valve and the actuator adopts a direct connection method, consisting of electric actuators such as UNIC, PSQ, HQ, DHL (other electronic electric actuators can also be configured according to user requirements) and ultra short ball valves. The electric actuator is equipped with a built-in servo system, without the need for an additional servo amplifier. It can be controlled to operate by inputting a 4-20mA signal and a 220V AC power supply. Compared with ordinary electric…
