5.08mm pitch 6pin terminal block with fixed screw

5.08mm pitch 6pin terminal block with fixed screw produced by Cixi XinKe Electronic Technology Co., Ltd. ,whitch is a factory mainly specializing in the production of plug-in terminal blocks, spring terminal blocks, PCB Screw Terminal Block and Barrier Terminal Block. We have 2pin -24pin position contacts for this type,good quality,sufficient stock and fast delivery,welcome to contact us!     Pitch:5.08mm;Poles:2P-24P;Rated Voltage/Current:300V/10A   female:     male:         Plastic material: PA66 Terminal material: brass Screw: Steel Rated voltage: 300V Rated current: 10A Wire range: 24-12AWG  2.5mm² Withstanding voltage: AC1600V/1Min Rated impules voltage: 4.0KV Temp.: -40℃~+105℃ Strip length: 7-8mm Pitch: 5.08mm   Other products you may also interested:1.Din Rail Terminal Block2.Barrier Terminal Block3.Spring Terminal Block4.Screw Terminal Block5.PCB Pluggable Terminal…
